Mark Audio ergo system 1s 121

ergo system
powerful, versatile and ultra-portable audio system

the ergo is an innovative portable audio system-concept with outstanding, accurate sound!
choose the ergo system fitting your needs, whatever the application: from small to large audiences, any kind of event or permanent installation. the satellites column design allows to rotate its configuration up to 360, this is important for both the audience and the players, since hearing everything greatly enhances both the performance and the listening experience.
they can also be used as personal monitors or as home desk.
let yourself and the audience hear your music at its best! always hear everything, everywhere in the venue!

main features:


total power 1.400 w
123 db max spl
frequency response 50 hz - 20 khz
8x2 neodymium full-range woofer stereo
1x12 subwoofer
innovative dsp processor
modularity, pole mountable, easy set-up and to transport

multiple applications:

pianobar
bands
permanent installations
meeting halls
home theater

acoustical
frequency response : 50 hz- 20 khz
max spl : 123 db
horizontal coverage angle : 120
vertical coverage angle : 30
satellites : 8 x 2, 16 ohm stereo
sub : 1 x 12 , 8 ohm
sub : ergo 121

input/output
input connectors : jack - xlr female - aux
output connectors : xlr male
input sensitivity : -1,1 dbu (@1khz)

processor
crossover frequencies :
protections : thermal, rms
limiter : soft limiter
controls : volume, eq

amplifier
total power (4ohm) : 1.400 w peak
high freq. power (4ohm) : 400 w peak (200w right + 200w left)
low freq. power (4ohm) : 1.000 w peak
total power rms (4ohm) : 700 w rms
high freq. power rms (4ohm) : 200 w peak (100w right + 100w left)
low freq. power rms (4ohm) : 500 w rms
cooling : convection
connections : vde connector

cabinet
handles :
cabinet material : multiply poplar
pole mount/cap :
colour : black

physical
system height (vertical sub) :
system height (horizontal sub) :
system widht :
system depth :
satellites weight :
subwoofer weight :
total weight :

accessories
optionals : satellites transport bag included
optionals : 2 x tripod stand (not included)
optionals : ergo 121 cover (not included)
